Specifications
System
| Model Number | 90-06801A |
| Current Rating | 200 A |
| Busbar Rating | 200 A |
| Off-Grid Switchover Time | < 0.03s |
| Overcurrent Protection Device | Up to 200 A |
| Number of Panelboard Spaces | 20 Spaces / 40 Circuits |
| AC Meter | Integral: +/- 0.2%, External (Rogowski Coil): +/- 5% |
| Warranty | 12.5 Years |
Mechanical
| Dimensions (H x W x D) | 26.7” x 14.1” x 9” (677 x 358 x 228 mm) |
| Mass | 44 lbs (20 kg) |
| Mounting | Wall or semi-flush mount |
Environmental
| Operating Temperature | -40°F to 140°F (-40°C to 60°C) |
| Ingress Rating | NEMA 3R |
Compliance
| Certifications | UL 1741, UL 67, UL 869A |
| Emissions | FCC Part 15 Class B |
