Specifications
System
| Model Number | 10-00522D |
| Rated Input DC Power | 650 W |
| Maximum Input Open Circuit Voltage (Voc) | 75 Vdc¹ |
| MPPT Operating Voltage | 20 Vdc - 60 Vdc |
| Maximum Input Short Circuit Current (Isc) | 20 A |
| Maximum Output Current | 16 A |
| PV String Length | 9-24 Modules |
| Parallel Strings of Different Lengths or Orientations | 3 Strings |
| Warranty | 25 Years |
Mechanical
| Dimensions (H x W x D) | 6.9” x 6.7” x 1.7” (176 x 169 x 43 mm) |
| Mass | 2 lb (936 g) |
| Mounting | Rack or panel mount |
| PV Connector | Stäubli MC4 |
Environmental
| Operating Temperature | -40°F to 185°F (-40°C to 85°C) |
| Ingress Rating | NEMA 4X, IP68 |
Compliance
| Certifications | UL 1741, CSA C22.2 107 |
| Emissions | FCC Part 15 Class B |
