Specifications
System
| Part Number | 90-004034 |
| Operating Voltage | 25 - 450 Vdc |
| DC Inputs | 3 DC PV strings (3+ & 3- wire terminals + 1 ground terminal) |
| Maximum Current Per Terminal | 50 A |
| Terminal Wire Size Range | 8 AWG - 20 AWG (Red / Black), 6 AWG - 16 AWG (Ground) |
| Internal Communications | Mesh Wi-Fi to Maximizers, PLC to Inverter |
| Warranty | 25 Years |
Mechanical
| Dimensions (H x W x D) | 11” x 12” x 4” (280 x 305 x 102 mm) |
| Mass | 2.3 lbs (1050 g) |
| Mounting | Rail mounting or comp shingle flashing |
Environmental
| Operating Temperature | -40°F to 185°F (-40°C to 85°C) |
| Ingress Rating | NEMA 3R |
Compliance
| Certifications | UL 1741, CAN/CSA C22.2 No. 107.1, CSA C22.2 No. 290 |
