1

Apply Metal Tape

The provided 7-inch metal tape must be attached from the conduit fittings to the inverter wall bracket (extending 2-3” onto the wall bracket) for both the AC and DC conduits.

If conduits are present on both sides, the tape must be applied to both sides.

2

Attach Magnet Strap

Attach the Inverter magnet strap to the top Battery Block.
